Features

• Support up to 4 M.2 NVMe SSD with Low-profile bracket for installation in small form-factor computers

• Support single power supply for each M.2 M Key connector with 3.3V and 5A.

• Clients can install different Lengths of M.2 SSD by moving the position of the screws which is more convenient for customers to replace SSD of different length.

Boost your system speed and performance

The expansion card lets you take full advantage of the fast performance and compact size of PCIe M.2 internal solid-state drives. The adapter connects directly to your computer motherboard to support an M.2 PCIe-based SSD (NVMe) through ultra-fast x4 PCIe. The adapter is compatible with PCIe 4.0 motherboards and is also backward compatible with PCIe 3.0,PCIe 2.0 and PCIe 1.0. With the M.2 PCIe based drive in place, the adapter gives your computer a significant speed boost.

Easy to install

The expansion card is equipped with a full-height bracket and includes a low-profile bracket, for installation in small form-factor computers.

Additional Settings Depending on the system, motherboard, and BIOS version, the following BIOS settings may be necessary for the proper operation of NVMe drives: Having the CPU IOU settings set to x4x4x4x4 PCIe bifurcation. This option may be found under BIOS Setup -> Advanced -> Chipset Configuration -> North Bridge -> IIO Configuration -> CPU Configuration -> IOU Setting -> x4x4x4x4.

Applications

Connect up to four PCIe M.2 NVMe SSD to your computer through an available x4 PCI Express bifurcation supported to boost system speed and increase internal data storage.

Get ultra-fast data access, ideal for gaming or high-performance workstations

Install your operating system on an M.2 PCIe based drive for fast access, while keeping larger platter drives available for bulk storage.
